Product Series: FRENIC-Ace (E2) Family Series: Fuji Drives, Ace Series HP Ratings : HND: 1.5, HHD: 1 Output Volt Range: 0 480V, 3-Phase Amps, 3-Phase HND: 3.4 HHD: 2.5 Amps, Single Phase Input, HND: Check Instruction Book HHD: Check Instruction Book Overload capability, HND: 120%-1 min HHD: 150%-1 min, 200%-0.5 s Watt loss @ Running, HND: 50, HHD: 40 Nominal Input Voltage, frequency: 460, 50/60Hz Input Volt Range: 380-480, +10 to -15% Max output Frequency: 500 Hz Digital Input: 5 (7) Analog Inputs: 2 Transistor outputs: 2 General purpose relay output: 1 Alarm relay output: 1 Braking Resistor Type: DB0.75-4 Braking Resistor QTY.: 1 Enclosure: Standard: IP20, UL open type Cooling: Natural cooling Weight/Mass [lbs.(kg) 3.3(1.5) Drawing Open Chassis: ROA701505 Dimensions H x W x D (inches): 5.51 x 4.33 x 5.63 NEMA Kit, : NEMA/UL Type 1: NEMA1-12E2-24 Option Cards, Communication Card, Modbus RTU: OPC-E2-RS DeviceNet: OPC-DEV , Profibus: OPC-PDP3, Profinet: OPC-PRT3 CC-Link: OPC-CCL, CANOpen: OPC-COP2 Multiprotocol Ethernet Interface: OPC-PRT3 Option Card, Input/Output Digital Output interface card: OPC-DIO , Analog Input / Output Interface Card: OPC-AIO PG Interface Card (5V): OPC-E2-PG, PG Interface Card (12V): OPC-E2-PG3 |
![]() |
